KYBER Power Supply Unit
- Intel ATX 3.1 Design Guide Compliant with 12VHPWR (12+4) Connector.
- Certified GOLD efficiency by both 80 PLUS and Cybenetics.
- Intelligent Fan-Curve Design and 105°C-Grade Capacitors.
- Available in 650W, 750W, and 850W models.
$79.00
(650W ATX 2.52)
$94.99
(750W)
$109.99
(850W)
DESCRIPTION
Next-Gen Ready - ATX 3.1 COMPATIBLE
KYBER power supply units adhere to the Intel ATX 3.1 design guide specifications and offering a 12V-2x6 connector at 750 and 850 wattage category, KYBER can support the latest graphics cards, made specifically for those who require high graphic capability and performance.
Cybenetics LAMBDA / ETA Certified
XPG KYBER SERIES is certified by Cybenetics for its efficiency and noise level, scoring at the top of its category in both ETA and LAMBDA standards. For more information please visit Cybenetics Labs – XPG PSU Efficiency & Noise Level Certifications.
GOLD Certified Efficiency
KYBER series power supply units 80 PLUS GOLD certified, achieving up to 91.40% (115V) efficiency at 50% load.
Intelligent Fan-Curve Design
The intelligent fan-curve ensures quiet operation in a majority of user scenarios. By starting the fan control at a low RPM, achieving less noise and a much longer lifespan for both the fan and the overall PSU.
8 Industrial Protections with 5-Year Warranty
KYBER is protected by 8 industrial-level mechanisms and backed up by a 5-Year Warranty to ensure the safety and stability of both the unit and the system.
PEAK PERFORMANCE AND RELIABILITY
All XPG ATX 3.0 and ATX 3.1 power supplies are designed to support up to 235% power excursion, enabling the system to handle sudden power spikes, ensuring stability, and preventing crashes during intense workloads like gaming, rendering, and data processing. Dimensions (L x W x H) | 140 x 150 x 86 mm |
---|---|
Cybenetics Rating |
850W: PLATINUM 750W/650W: GOLD |
80 Plus Rating | GOLD |
ATX Version |
850W /750W : ATX 3.1 650W : ATX 2.4 |
Protections | OVP / OPP / SCP / OCP / UVP / OTP / NLO / SIP |
Certification | CB/TUV/cTUVus/CE+UKCA/FCC+IC/LVD+UKCA/BSMI/RCM/BIS/EAC+ROHS/S-MARK/NOM |
PFC | >0.99 |
Input Voltage | 100V-240V |
Input Current |
850W : 12A 750W : 10A 650W :10A |
Input Frequency | 47 – 63 Hz |
DC Output Voltage | +5V | +3.3V | +12V | -12V | +5Vsb |
Total Output | 850W /750W /650W |
Power Excursion |
850W: 1700W (*up to 200% of the PSU's rated power for 100μs) 750W: 1500W (*up to 200% of the PSU's rated power for 100μs) |
Operating Temperature | 40 °C |
Fan Size | 120 x 120 x 25mm |
Fan Bearing | FDB |
Fan Speed | 2400 |
MTBF | 100,000 hours |
ATX 24 Pin Connector | 1 |
EPS 8 (4+4) Pin Connector | |
EPS 8 Pin Connector | 2 |
PCI-E 6+2 Pin Connector |
850W : 2 750W : 2 650W : 2 |
Molex 4 Pin Connector |
850W : 2 750W : 2 650W : 2 |
12VHPWR (12 + 4) Connector (600W) |
850W : 1 750W : 1 650W : 0 |
12V-2x6 (12+4) Connector (600W) | |
12V-2x6 (12+4) Connector (600W) | |
12V-2x6 (12+4) Connector (450W) | |
12VHPWR (12 + 4) Connector (450W) | |
SATA Connector |
850W : 6 750W : 6 650W : 6 |
Weight |
850W : 2.032Kg 750W :2.024Kg 650W :1.768Kg |
Warranty | 5 Years |
Floppy 4 Pin Connector | |
12V-2x6 (12+4) Connector (600W) | |
12V-2x6 (12+4) Connector (450W) | |
remark |
